Motenergy motor, ME1003 PMDC, Air cooling

Motenergy ME1003 PMDC electric motor
Brush-Type motor.
Permanent Magnet Direct Current motor
Efficiency 92% at 48 VDC.
Rotation speed 48 RPM per Volt
Rotation speed 570 RPM  at 12VDC.
Rotation speed 2300 RPM at 48VDC.
Rotation speed 3450 RPM at 72VDC.
Controller input voltage 12 à 72 VDC.
Constant torque at 0.20 Nm/Amp.
Rated power 11,5kW, peak 20kW (28hp).
Rated current 200A continuous
Rated torque 35Nm at 200A.
Max. DC current 400A during 30sec.
Max. torque 80Nm at 400A.
No temperature sensor
Output motor shaft 7/8"
Shaft key 3/16"
Recommended power cable 70mm² with 8mm lugs
Regen current in brake mode 5,6A per Nm
Brushes life about 1500 hours
Weight 17,9 Kg
Dimensions : Diam. 200mm x 188mm
