Motorcycle 50cc conversion kit, P4 36V-48V AC

This P4 36V-48V AC 50CC motorcycle electric conversion kit contains :

- 1 * Wheel hub motor 17" brushless 4kW
- 1 * ZAPI BLE-0 PW 36V-48V 320A controller with preset
- 1 * Harness for Zapi BLE-0 controller
- 1 * Hall effect twist thottle + handlebar
- 1 * Emergency stop button + main contactor relay 200A
- 1 * Fork circuit cutter
- 2 * Meters of 35mm² orange cable + batteries lugs + orange lugs cover
- 1 * Dash board with speedometer and battery state of charge indicator
- Thermal heatshrink, hose clamp et 6mm support, assembly instruction included.

We can crimp lugs on power cable, cut to measure, ask us.

Technical description of P4 36V-48V AC 50CC motorcycle electric conversion kit :

- Rated voltage : 36V-48V
- Working voltage : 26V à 57V
- Rated current : 100Arms
- Maximum current : 200Arms
- Rated power : 4kW
- Maximum power : 8kW
- Rated torque : 100Nm
- Maximum torque : 250Nm
- Maximum speed : 80km/h
- Complet set weight : 33kg
- Working température : -20°C à 50°C

Rated performance are given for pre-settled controller.

Kit typical use :

This lot of equipment allows the conversion of 2 light wheels into electric (scooter, small motorcycle). It may also be suitable for other applications, consult us before placing an order.
