Waterproof fuse holder for ATO 32V fuse type pluggable tongue Available in 4, 6, 8 and 10 channel Independent and isolated channels Current max. by way 40A Transparent cover with seal. Fixing the fuse box by 2 screws M5 Standards SO 8820, SAE J 1284, DIN 72581, UL 248, RoHS
Fuse holder DIN43560 R1025 with protective cover 60mm fuse screw spacing Current up to 500A Voltage up to 100V M8 fuse fixing screw External holder size with cover : L = 88mm * l = 30mm * h = 43mm Fuse holder fixing by 2 holes, screw FHC M6, spacing 25mm.
ATO / ATC Automotive Fuses Fuse with rectangular tongue Fast acting and resistant to corrosion Excellent resistance to heat and mechanical shock Rated voltage 32VDC Current range from 1A to 32A Cutoff capacity 1000A to 32V Dimensions 5.1mm x 19.1mm x 18.8mm Operating temperature -55 to + 125 Standards SO 8820, SAE J 1284, DIN 72581, UL 248, RoHS
Waterproof fuse holder for APM/ATM 32V fuse type pluggable tongue Available in 4, 6, 8 and 10 channel Independent and isolated channels Current max. by way 40A Transparent cover with seal. Fixing the fuse box by 2 screws M5 Standards SO 8820, SAE J 1284, DIN 72581, UL 248, RoHS
APM / ATMAutomotive Fuses Fuse with rectangular tongue Fast acting and resistant to corrosion Excellent resistance to heat and mechanical shock Rated voltage 32VDC Current range from 1A to 32A Cutoff capacity 1000A to 32V Dimensions 10,9mm × 3,6mm × 16.3 mm Operating temperature -55 to + 125 Standards SO 8820, SAE J 1284, DIN 72581, UL 248, RoHS
